BATTEN FLAT P YOUR RELIABLE PARTNER FOR EVERY INSTALLATION. Profishop powered by
VALUE Reliable essentials for cost-efficient projects. CORE The perfect balance between price and performance. PERFORMANCE High-performance lighting for demanding projects. FOLLOW THE BLUE STAR - THE NEW SLVtec® PRODUCT RANGE THREE PERFORMANCE CLASSES. COUNTLESS POSSIBILITIES. ONE ANSWER: SLVtec® Whether you are looking for cost-efficient basic lighting, the ideal balance between price and performance or sophisticated lighting solutions: SLVtec® has the right answer for you. All our products combine innovative technology, efficient light output and versatile applications for professionals who rely on function and quality every day. Scan, discover, get started – with the right SLVtec® solution for your project at profishop.online EASYLIGHT & RETRO LED continuous-row lighting systems with up to 200 lm/W, 100,000 h service life and tool-free installation PAVANNO Up to 190 lm/W, 100,000 h service life and UGR<19 TRACKSPOT P Up to 170 lm/W, 75,000 h service life and CRI>90 OUR HIGHLIGHTS
BATTEN FLAT P The BATTEN FLAT P is a compact and versatile luminaire with an IP44 protection rating that has been developed for numerous indoor applications – from car parks, schools and corridors to washrooms, kitchens and industrial buildings. The innovative end cap design reduces installation time by up to 80 % – a clear advantage for those seeking to minimise both time and cost. BATTEN FLAT P AT A GLANCE Low glare for pleasant indoor lighting Halogen-free - environmentally friendly and safe Service life of up to 100,000 hours EASY TO INSTALL thanks to the smart end cap – easy to open, quick installation Flexible and adaptable thanks to Multi-Lumen and Multi-Colour Available upon request: integrated emergency lighting function, smart microwave sensors with presence and daylight control and flexible DALI2 or 0 –10V dimming options Adjustable luminous flux Selectable colour temperature – DIP switch on the driver for 1010907, 1010908, 1010909, 1010911, 1010916 and 1010918 Selectable colour temperature – external DIP switch on 1011094, 1010910, 1010912, 1010913, 1010914, 1010915, 1010917, 1010919, 1010928, 1010929, 1010930, 1010919, 1010928, 1010929 and 1010930 Optional beam angle 120° 3
OPAL DIFFUSER EMERGENCY LIGHTING OPTION The high-quality opal diffuser ensures uniform light distribution without glare – ideal for work environments where visual comfort is paramount. For maximum safety, the light fitting is optionally available with an integrated emergency lighting module. In the event of a power failure, the LiFePO4 battery provides up to 3 hours of emergency lighting. EASY TO OPEN The clever end cap design allows the light fitting to be opened in a few simple steps. This reduces installation time by up to 80 % and makes both installation and maintenance particularly efficient. Step 3 Step 2 Step 1 Microprismatic surface 4
MIRCOWAVE SENSOR (OPTIONAL) The light remains switched off during the day, even if movement is detected. (The ambient light is above the preset brightness threshold). The light is automatically activated by the sensor upon detection of movement and insufficient ambient light. If no further movement is detected, the light automatically switches off again after the preset hold time has elapsed. Sensitivity Hold time Daylight sensor Detection range 25% / 50% / 75% / 100% 5 s / 30 s / 1 min / 3 min / 5 min / 10 min / 20 min / 30 min 2 lux / 10 lux / 25 lux / 50 lux, deactivated Max. Ø 10 m @ 3 m 5
BATTEN FLAT P IP44 IK04 INDOOR BATTEN FLAT P Product designation Colour Max. Total wattage Mains voltage Luminous flux (from - to) Max. Efficiency Colour temperature BATTEN FLAT P 600 27 830/840/850 ML WH 20 W 220-240 V 1.619 - 2.598 lm 130 lm/W 3.000 K 1.718 - 2.837 lm 142 lm/W 4.000 K 1.698 - 2.748 lm 137 lm/W 5.000 K BATTEN FLAT P 600 27 830/840/850 ML Microwave WH 20 W 220-240 V 1.619 - 2.598 lm 130 lm/W 3.000 K 1.718 - 2.837 lm 142 lm/W 4.000 K 1.698 - 2.748 lm 137 lm/W 5.000 K BATTEN FLAT P 600 27 830/840/850 ML DALI2 WH 20 W 220-240 V 1.505 - 2.475 lm 123 lm/W 3.000 K 1.556 - 2.616 lm 135 lm/W 4.000 K 1.578 - 2.612 lm 131 lm/W 5.000 K BATTEN FLAT P 1200 52 830/840/850 ML WH 35 W 220-240 V 2.927 - 4.849 lm 139 lm/W 3.000 K 3.103 - 5.293 lm 151 lm/W 4.000 K 3.069 - 5.113 lm 146 lm/W 5.000 K BATTEN FLAT P 1200 52 830/840/850 ML Microwave WH 35 W 220-240 V 2.927 - 4.849 lm 139 lm/W 3.000 K 3.103 - 5.293 lm 151 lm/W 4.000 K 3.069 - 5.113 lm 146 lm/W 5.000 K BATTEN FLAT P 1200 52 830/840/850 ML EM 3H WH 35 W 220-240 V 2.927 - 4.849 lm 139 lm/W 3.000 K 3.103 - 5.293 lm 151 lm/W 4.000 K 3.069 - 5.113 lm 146 lm/W 5.000 K BATTEN FLAT P 1200 52 830/840/850 ML EM 3H Microwave WH 35 W 220-240 V 2.927 - 4.849 lm 139 lm/W 3.000 K 3.103 - 5.293 lm 151 lm/W 4.000 K 3.069 - 5.113 lm 146 lm/W 5.000 K BATTEN FLAT P 1200 52 830/840/850 ML DALI2 WH 35 W 220-240 V 2.609 - 4.492 lm 128 lm/W 3.000 K 2.754 - 4.887 lm 140 lm/W 4.000 K 2.741 - 4.720 lm 135 lm/W 5.000 K BATTEN FLAT P 1200 52 830/840/850 ML DALI2 EM 3H WH 35 W 220-240 V 2.609 - 4.492 lm 128 lm/W 3.000 K 2.754 - 4.887 lm 140 lm/W 4.000 K 2.741 - 4.720 lm 135 lm/W 5.000 K BATTEN FLAT P 1200 49 830/840/850 ML Bluetooth Microwave WH 35 W 220-240 V 2.927 - 4.849 lm 139 lm/W 3.000 K 3.103 - 5.293 lm 151 lm/W 4.000 K 3.069 - 5.113 lm 146 lm/W 5.000 K *S = in stock O = available to order For the EM 3H emergency lighting variants, the following luminous flux is provided during 3-hour battery operation: 3,000 K, 3 W, 411 lm 4,000 K / 5,000 K, 3 W, 435 lm 6
CRI Ambient temperature Weight Control DC-compatible Availability* Product no. GBP 100.000h L80B10 >80 120° 3-core -20° + 40°C 2,03 kg On / Off S 1010907 77.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 2,03 kg On / Off S 1010908 94.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 2,03 kg DALI2 S 1011094 111.00 100.000h L80B10 >80 120° 3-core -20° + 40°C 3,56 kg On / Off S 1010909 119.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 3,56 kg On / Off S 1010911 136.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 3,56 kg On / Off O 1010912 179.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 3,56 kg On / Off O 1010914 196.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 3,56 kg DALI2 S 1010910 153.00 100.000h L80B10 >80 120° 6-core -20° + 40°C 3,56 kg DALI2 S 1010913 221.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 3,56 kg 0-10V dim + SILVAIR Bluetooth O 1010915 238.00 7
BATTEN FLAT P IP44 IK04 INDOOR BATTEN FLAT P Product designation Colour Max. Total wattage Mains voltage Luminous flux (from - to) Max. Efficiency Colour temperature BATTEN FLAT P 1500 72 830/840/850 ML WH 50 W 220-240 V 4.331 - 7.066 lm 141 lm/W 3.000 K 4.579 - 7.700 lm 154 lm/W 4.000 K 4.522 - 7.467 lm 149 lm/W 5.000 K BATTEN FLAT P 1500 72 830/840/850 ML Microwave WH 50 W 220-240 V 4.331 - 7.066 lm 141 lm/W 3.000 K 4.579 - 7.700 lm 154 lm/W 4.000 K 4.522 - 7.467 lm 149 lm/W 5.000 K BATTEN FLAT P 1500 72 830/840/850 ML EM 3H WH 50 W 220-240 V 4.331 - 7.066 lm 141 lm/W 3.000 K 4.579 - 7.700 lm 154 lm/W 4.000 K 4.522 - 7.467 lm 149 lm/W 5.000 K BATTEN FLAT P 1500 72 830/840/850 ML EM 3H Microwave WH 50 W 220-240 V 4.331 - 7.066 lm 141 lm/W 3.000 K 4.579 - 7.700 lm 154 lm/W 4.000 K 4.522 - 7.467 lm 149 lm/W 5.000 K BATTEN FLAT P 1500 72 830/840/850 ML DALI2 WH 50 W 220-240 V 4.124 - 6.909 lm 138 lm/W 3.000 K 4.362 - 7.532 lm 151 lm/W 4.000 K 4.315 - 7.258 lm 145 lm/W 5.000 K BATTEN FLAT P 1500 72 830/840/850 ML DALI2 EM 3H WH 50 W 220-240 V 4.124 - 6.909 lm 138 lm/W 3.000 K 4.362 - 7.532 lm 151 lm/W 4.000 K 4.315 - 7.258 lm 145 lm/W 5.000 K BATTEN FLAT P 1500 70 830/840/850 ML Bluetooth Microwave WH 50 W 220-240 V 7.066 - 4.331 lm 141 lm/W 3.000 K 7.700 - 4.579 lm 154 lm/W 4.000 K 4.522 - 7.467 lm 149 lm/W 5.000 K *S = in stock O = available to order For the EM 3H emergency lighting variants, the following luminous flux is provided during 3-hour battery operation: 3,000 K, 3 W, 411 lm 4,000 K / 5,000 K, 3 W, 435 lm 8
CRI Ambient temperature Weight Control DC-compatible Availability* Product no. GBP 100.000h L80B10 >80 120° 3-core -20° + 40°C 4,12 kg On / Off S 1010916 145.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 4,12 kg On / Off S 1010918 162.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 4,12 kg On / Off O 1010919 204.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 4,12 kg On / Off O 1010929 221.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 4,12 kg DALI2 S 1010917 179.00 100.000h L80B10 >80 120° 6-core -20° + 40°C 4,12 kg DALI2 O 1010928 247.00 100.000h L80B10 >80 120° 5-core -20° + 40°C 4,12 kg 0-10V dim + SILVAIR Bluetooth O 1010930 264.00 9
130 x 70 x 35 L x W x H (mm): 85 x 30 x 12 2000 L x W x H (mm): L (mm): 40 x 35 x 32 L x W x H (mm): 52 x 6 x 85 L x W x H (mm): OPTIONAL ACCESSORIES Product designation Colour Availability* Product no. GBP Wall brackets 2 pieces S 1010931 11.00 Suspension kit 2000mm S 1010932 15.00 Horizontal cable suspension kit 2 pieces S 1010933 6.00 Microwave sensor On/Off S 1010934 17.00 Remote control PIR sensor S 1011005 11.00 *S = in stock O = available to order 1010931 1010932 1010933 1010934 10
Through-wiring possible Protection class I / Protective conductor SYMBOLS KEY IP protection rating IK impact resistance rating Many of the products shown in this catalogue are protected by trademarks, registered designs, utility models or patents. Any violation of these property rights or the use of text and layout design or copyrighted images without our authorisation will be prosecuted. The illustrations and information contained in this catalogue are for illustrative purposes only and are not legally binding in terms of colour, shape, design or technical details. All product descriptions/information are therefore subject to change and errors excepted. All products in our range are subject to our strict quality assurance procedures and comply with generally applicable standards. This catalogue contains a general range and is not country-specific. Any deviations from country-specific guidelines must be clarified before ordering. SLV cannot be held responsible for any deviations in terms of technical standards. All weights and dimensions are given in kg and cm respectively unless stated otherwise. We reserve the right to make technical changes. The presentation of our lights with realistic photos showing them in use is possible thanks to the kind cooperation and agreement of the owners or designers of the environments depicted in the images. We would like to take this opportunity to thank all those who consented to having photos taken and used. The publication of this catalogue invalidates the prices specified in previous lists and catalogues. SLV is entitled to adjust the respective price list to changing market conditions, in the event of significant changes in procurement costs, changes in value-added tax or procurement prices. All prices are recommended retail prices (RRP) and indicated in GBP without VAT. Publisher SLV GmbH, Germany Daimlerstrasse 21-23 52531 Übach-Palenberg T +49 (0) 2451 4833-0 slv.com Copyright © SLV GmbH, 2025 Connected lighting: Bluetooth Multi-Colour describes the ability of a light to produce different light colours. For lights with adjustable Multi-Colour, the light colour can be adjusted using a switch. This is technically achieved by installing multiple LED chips of different colours. By changing the switch status, the proportion of the respective LEDs is adjusted to produce the desired light colour. The Multi-Lumen function enables gradual adjustment of the light output, allowing you to tailor the lighting to suit your needs. 11
