LED Ceiling recessed spot KADUX Triple, 3x6,2W, COB LED, 3000K, 38°, incl. Driver, Clip springs, black

SLV


E
Product data sheet

You do not have the permission to see the prices

Shipping time: in stock

Product no.: 115720
EAN: 4024163158053
In stock



SLV LED Ceiling recessed spot KADUX Triple, 3x6,2W, COB LED, 3000K, 38°, incl. Driver, Clip springs, black

High-Quality LED Recessed Ceiling Spotlight KADUX TRIPLE

The LED recessed ceiling spotlight KADUX TRIPLE from SLV impresses with its modern technology and high-quality workmanship. Equipped with three COB LEDs, each delivering 6.2 watts of power at a warm white color temperature of 3000K, the spotlight produces a pleasant total luminous flux of 1920 lumens. The luminaire is specially designed for efficient lighting and offers a luminous efficacy of 96 lumens per watt, ensuring bright and energy-saving illumination.

Technical Details for Optimal Light Quality

The recessed ceiling spotlight features a beam angle of 38 degrees, which distributes light precisely and without glare. With a color rendering index of 80Ra, colors are displayed naturally and vividly. The average lifespan of the LEDs is an impressive 40,000 hours, keeping maintenance requirements minimal. The integrated electronics allow for direct connection to a mains voltage of 220-240V and ensure stable power supply with a built-in driver.

Flexibility and Easy Installation

The KADUX TRIPLE is made with a robust housing of painted aluminum and steel, which is not only durable but also visually appealing. The recessed spotlight is equipped with spring clips that enable simple and secure mounting in ceilings with a maximum material thickness of 30 mm. The luminaire head can be tilted 30 degrees to each side, allowing flexible light positioning according to individual needs.

Dimmability for Individual Lighting Atmosphere

This recessed spotlight is dimmable and supports both phase-cut and phase-control dimmers, allowing continuous adjustment of light intensity. This enables the lighting to be dimmed depending on the situation to create a pleasant atmosphere or save energy. However, a dimmer is not included and must be purchased separately.

Versatile Applications and Accessories

The KADUX TRIPLE is part of an extensive series of recessed spotlights available with integrated LED modules or interchangeable reflector lamps. The included accessories comprise the appropriate driver, ensuring safe and reliable power supply. The IP20 protection rating offers good protection against contact and dust, ideal for many applications. Upon request, a light distribution curve can be provided to support optimal placement and alignment of the luminaire.

Colour:
black
Glass color:
clear
Reflector color:
silver,faceted
Dimension:
total-L∕ B∕ H: 21∕ 9∕ 8,5 cm
visible part-L∕ B∕ H: 21∕ 9∕ 0,5 cm
max. material thickness-H: 3 cm
Material:
aluminium
steel
lacquered
Weight:
0,75 kg
Product type:
recessed spotlight
Accessories:
driver - included in delivery
dimmer - not included in delivery
Operating voltage:
220-240 V~
Dimmable:
yes
Dimmability:
trailing edge,leading edge
Power frequency:
50/60 Hz
Power consumption:
18,6 W
Emitting angle:
38 °
Number of bulbs:
3
Light colour:
warm white
Beam direction:
swivelling
Light flux:
1920 lm
Light yield:
96 lm/W
Colour temperature:
3000 K
Average life span of a bulb in hours:
40000 h
Colour rendering index:
80 Ra
1B
IK-Rating:
IK02 up to 0.20 Joule
Fitting depth:
8 cm
Fitting opening length:
20 cm
Fitting opening width:
8 cm
Protection class:
2
IP-protection class:
IP20
Additional information:
Integrated converter for 200-240V AC voltage to 350mA constant DC.
Dimmable with Phase section dimmer / Phase-fired dimmer
We will be pleased to send you a light distribution curve for the respective product on request.
Material thickness Ceiling: 30mm max.
Lamp head can be swiveled
Robust luminaire housing
Premium LED
System power: 22W
Energy efficiency category:
E
EPREL No:
916451
Energy consumption:
20 kWh/1.000 h
Article number:
115720
Purchasing quantity:
1 piece
Brand:
SLV
Manufacturer:
SLV
Manufacturer information
SLV GmbH, Daimlerstraße 21-23, 52531, Übach-Palenberg, Germany, info@slv.de
