LED Outdoor Wall luminaire SITRA M WL UP/DOWN, CCT switch 3000/4000K, white

SLV




LED Outdoor Wall Light SITRA M WL UP/DOWN, IP65 IK05, 20cm, 14W 3000/4000K (CCT Switch) 1700lm 2x95°

The LED outdoor wall light SITRA M WL UP/DOWN is a square wall light specifically designed for outdoor use. With a power of 14W and a luminous flux of 1700lm, it provides bright light for your outdoor spaces. The light color can be easily switched between warm white and neutral white using a slide switch.

Application and Material

This wall light is ideal for use on outdoor walls. Made of high-quality aluminum and glass, it is durable and robust. The symmetrical light distribution ensures uniform illumination of your facade or terrace.

Technical Details

The LED modules are fixed and not replaceable. With a beam angle of 2x95°, the light provides wide coverage. The energy consumption is 14kWh/1,000h, and the light has an energy efficiency class of D. The color rendering index is 80Ra.

Installation and Accessories

The installation is simple and straightforward with surface mounting. The mounting accessories, driver, and light color switch are included in the delivery. The light is directly connected to 230V AC mains voltage and is ready for use immediately.

Additional Information

The LED outdoor wall light SITRA M WL UP/DOWN has an IP65 protection against water and dust as well as an IK05 protection against accidents and vandalism. With dimensions of 20 x 11 x 8.4 cm and a weight of 1.256 kg, it is compact and easy to install. Discover the versatile applications of this modern outdoor light!

Colour:
white
Glass color:
partly satined
Dimension:
W∕ H∕ D: 20∕ 11∕ 8,4 cm
Material:
aluminium
glass
Weight:
1.457 kg
Product type:
outdoor wall luminaire
luminary type:
Wall luminaire
Lamp shape:
square
Bulbs in delivery:
yes
Accessories:
light colour switch - included in delivery
mounting accessories - included in delivery
driver - included in delivery
Application area:
suitable for outdoor use
Field of application:
wall
Operating voltage:
100-277 V~
Dimmable:
no
Power frequency:
50/60 Hz
Power consumption:
14 W
Emitting angle:
2x 95 °
LED can be replaced :
no
Bulb type:
LED
Lamps/bulbs:
AC SMD-LED module, permanently installed
Voltage:
Clamp
Light colour:
warm white / neutral white (in steps)
Light emission:
symmetriccal
Beam direction:
up / down
Light flux:
@3000K: 1600 / @4000K: 1700 lm
Light yield:
121,43 lm/W
Nominal current:
350 mA
Colour temperature:
3000 / 4000 K
Average life span of a bulb in hours:
50000 h
Colour rendering index:
80 Ra
1B
IK-Rating:
IK05 up to 0.70 Joule
Max. current carrying capacity:
10.00 A
Current consumption:
10.00 A
Plug type:
clamping connection
Mounting:
surfaced mounting
Protection class:
1
IP-protection class:
IP65
Additional information:
Available in anthracite, white and rust colors
ambient temperature:
-20 ... +40 °C
Energy efficiency category:
D
EPREL No:
916403
Energy consumption:
14 kWh/1.000 h
Article number:
1005153
Purchasing quantity:
1 piece
Brand:
SLV
Manufacturer:
SLV
Manufacturer information
SLV GmbH, Daimlerstraße 21-23, 52531, Übach-Palenberg, Germany, info@slv.de
